| Camera |
| Image Sensor: |
1/4″ SONY CCD |
| Effective Pixels: |
PAL:976(H)×582(V)
NTSC:976(H)×494(V) |
| Horizontal Resolution: |
Color: 700 TVL
B/W: 750 TVL |
| Signal System: |
PAL/NTSC |
| Min.illumination: |
0.02Lux/(F1.6, AGC ON), 0.0008Lux /(F1.6, AGC ON, sensitivity×256) (color)
0.002Lux/(F1.6, AGC ON), 0.00008Lux /(F1.6, AGC ON, sensitivity×256)(B/W) |
| White Balance: |
Auto / Manual / ATW / Indoor / Outdoor |
| AGC: |
Auto/Manual |
| S/N Ratio: |
≥ 50dB |
| DNR: |
3D DNR |
| WDR: |
128x (on / off / auto) |
| Shutter time: |
PAL: 1-1/10,000s
NTSC: 1-1/10,000s |
| Day&Night: |
ICR |
| Digital Zoom: |
16x |
| Privacy Masking: |
8 privacy masks programmable; a maximum of 8 zones can be masked simultaneously on the same video screen |
| Focus Mode: |
Auto / Semi-automatic / Manual |
|
| Lens |
| Focal Length: |
3.3-119mm, 36X |
| Zoom Speed: |
Approx.6 s(Optical Wide-Tele) |
| Angle of View: |
57.1-1.7 degree(Wide-Tele) |
| Minimum Working Distance: |
10-1000mm (Wide-Tele) |
| Aperture Range: |
F1.4-F3.7 |
|
| Pan & Tilt |
| Pan Range: |
360° endless |
| Pan Speed: |
Pan Manual Speed: 0.1°-250°/s,
Pan Preset Speed: 300°/s |
| Tilt Range: |
-5°~90° (Auto Flip ) |
| Tilt Speed: |
Tilt Manual Speed: 0.1°-150°/s,
Tilt Preset Speed: 200°/s |
| Proportional Zoom: |
Rotation speed can be adjusted automatically according to zoom multiples |
| Number of Preset: |
256 |
| Patrol: |
8 patrols, up to 32 presets per patrol |
| Pattern: |
4 patterns, with the total recording time not less than 10 minutes |
| Power-off Memory: |
Support |
| Park Action: |
Preset / Patrol / Pattern / Pan scan / Tilt scan / Frame Scan / Random scan / Panorama scan |
| PTZ Position Display: |
ON/OFF |
| Compass: |
Support , the north can be set |
| Scheduled Task: |
Preset / Patrol / Pattern / Pan scan / Tilt scan / Random scan / Frame scan / Panorama scan |
|
| General |
| Menu Language: |
English / Chinese |
| RS-485 Protocols: |
HIKVISION, Pelco-P, Pelco-D, self-adaptive |
| Power Supply: |
24V AC |
| Power Consumption: |
Outdoor dome: Max. 20W (Heater On), Max. 12W(Heater Off)
Indoor dome: Max.12W |
| Working Temperature /Humidity: |
-30 ?-65?(-22?-149?)(outdoor dome) / -10?-50?(14?-122?)(indoor dome )
90% or less |
| Protection Level: |
IP66 standard (outdoor dome)
TVS 4,000V lightning protection, surge protection and voltage transient protection |
| Mounting: |
Various mounting modes option |
| Dimensions: |
Φ220×305mm (Φ8.66”×12.00”)(Outdoor) |
| Weight(approx.): |
5Kg (11.02Ibs) |
| Mount Option: |
Long-arm wall mount: DS-1601ZJ;Corner mount: DS-1633ZJ; Pole Mount: DS-1622ZJ; Power box mount:DS-1634ZJ |
|
